SASF-S3-B-F-A30 Festo Position Indicator
Product Code: SASF-S3-B-F-A30
Festo SASF-S3-B-F-A30 Position Indicator
Festo part number: 8140397
Position indicator for quarter turn actuators to show valve status. Indicator has metal inserts to activate sensor box SRBI-C2-N-1-P-M12
Fits Festo DFPD quarter turn actuators from size DFPD-240 up to DFPD-480
For mounting on the drive shaft of standard actuators to VDI/VDE 3845
Rotation angle adjustment range: 0 ... 90 deg
Dimensions: 40mm Diameter x 43mm High
Ambient temperature: -25 ... 70 °C
Mounting type: To VDI/VDE 3845
-
$39.30
Qty
